The Allen & Heath Avantis Digital Mixer was built to revolutionize the way you mix live sound. Equipped with the same dLive technology as Allen & Heath's flagship mixers, the Avantis is a 64-channel / 42 bus compact console that strikes the perfect balance between old-school analog mixing and cutting-edge digital processing. Those who love analog mixers will appreciate the 24 channel strips complete with manual faders and PAFL switches. The unit has dual 15.6" DSP touchscreens that offer gesture control, fully-customization routing options, and 144 fader strips (24 faders, 6 layers). Whether it's handling a few mic connections or synchronizing gear with the word clock and connecting to a Dante network, the Avantis can handle all your live sound needs.

96kHz 64 channel / 42 bus digital mixer
XCVI FPGA core with ultra-low latency (0.7ms)
Fully configurable mix bus architecture
Super-tough, full metal chassis
Continuity UI seamlessly connects physical and touchscreen controls for the fastest, most intuitive workflows
dPack option adds dLive processing, including 16 Dyn8 engines, plus per-channel zero-latency DEEP Compressors and Dual-Stage Valve preamp
12 RackExtra FX slots with dedicated stereo returns
16 DCAs
Dual 15.6” Full HD capacitive touchscreens with gesture control
AMM (Automatic Mic Mixer) up to 64 channels across 1, 2 or 4 zones
Fully assignable layout
144 fader strips (24 faders, 6 layers) with optional dedicated master section
SLink port for connection to Remote I/O Expanders and the ME Personal Mixing System
12 analogue XLR Inputs / 12 analogue XLR Outputs
1 Stereo AES In / 2 Stereo AES Out
2 I/O Ports, both capable of 128x128 operation at 96kHz – for optional cards inc. Dante, MADI and gigaACE
User configurable rotary controls
24 assignable SoftKeys
Comprehensive metering with multi-point peak detection
Internal storage for stereo playback and recording
USB stereo playback
BNC Word Clock

The power of Avantis emanates from the XCVI Core – pioneered by the Allen & Heath R&D team using next generation FPGA technology, with parallel virtual processing cores generating enough power for 88×42 (including FX returns) channels of processing at 96kHz sampling rate.

The massive power of XCVI (25 billion operations per second) allows Avantis to deliver 64 full processing inputs and 12 stereo FX returns, 42 bus with configurable mix architecture, variable bit depth for ultimate precision and noise performance, a virtually infinite mix headroom thanks to a 96bit accumulator, and class-leading latency at an ultra-low 0.7ms.
